Build your lighting display YOUR way with Nanoleaf Blocks! Create your one-of-a-kind illuminated display with different panel styles and add-ons. Customise with colours and lighting effects, and utilise the new Shelves and Pegboards to show off your favourite items that make you YOU - like your gaming accessories, collectibles, plants, and more!
With modular light panels, pegboards, and shelves that can be mixed and matched, you have total design freedom to create a statement lighting piece that doubles as a versatile display and storage solution.
Mix and match from 5 Blocks styles for a lighting layout that's totally unique to you. Take customisation one step further by creating your own colour palettes and animated Scenes.
Sleek square panels with even edge-to-edge lighting give you complete creative flexibility to go ultra minimalistic or take it to the max.
Note: This kit contains components that must be screw-mounted onto the wall.
Mix of Large & Small Panel sizes
Edge to edge illumination
Includes Light Pegboard & Shelf for display and organisation
App, voice, manual control
Shelf weight limit: 1.5kg
Pegboard weight limit: 3kg
What's in the box:
4 x Squares
4 x Small Squares
1 x Light Pegboard
2 x Pegboard Hooks
1 x Shelf
1 x Shelf Cover
1 x Controller
Mounting Plates & Tapes
Screws
Rigid Linkers
100VAC-240VAV Power Supply
Specifications:
Dimensions
Squares - 231*231*29 mm
Small Squares - 115.5*115.5*29 mm
Textured Squares - 231*231*29 mm
Light Pegboard - 231*231*29 mm
Pegboard Hook - 79.5*76.6*5.5 mm
Shelves - 229.6 x 70 x 129 mm
Shelf Cover - φ5.5*79.7*76.6 mm
Cable Length - 2m
Controller - 230*35*29 mm
Weight
Squares (Per Panel) - 550g
Small Squares (Per Panel) - 135g
Textured Squares (Per Panel) - 492g
Light Pegboard (Per Panel) - 900g
Pegboard Hook - 26g
Shelf - 227.5g
Shelf Cover - 26g
PSU - 205g
Controller - 40g
Shelf Load Bearing Capacity - 1.5kg
Light Pegboard Load Bearing Capacity - 3kg
Features
Screen Mirror - Yes
Rhythm Music Visualiser - Yes
Sync+ - Yes
Connect+ - Yes, panels can be connected with other Nanoleaf Blocks & Nanoleaf Shapes
Touch Control - No
General
Luminous Per Display
Squares: 320 lumens
Small Squares: 70 lumens
Textured Squares: 230 lumens
Light Pegboard: 62 lumens
Communication Protocol - WiFi (2.4 GHz b/g/n)
NOTE: 5 GHz networks are not compatible with Nanoleaf products.
Light Pegboard: Must be screw mounted (screws provided)
Shelves: Must be screw mounted (screws provided)
The Nanoleaf App - Control via Nanoleaf App (Android & iOS) for mobile/tablet or The Nanoleaf Desktop App (Windows & Mac).
Thread Compatibility - Can act as a Thread Border Router with a future firmware update
Compabitility - Apple Home, Amazon Alexa, Google Home, SmartThings, Razer Chroma
Colour
Colour Temperature -1200K-6500K
Colour Channel Configuration - RGBW
Max Colours - More than 16 million
Colour Rendering Index (CRI) - 80
Power
Voltage100 - 240V AC
Max Panels per Power Supply (42W)
Squares: 17
Light Pegboard: 17
Textured Squares: 17
Small Squares: 60
Max Panels per Controller - 500
Individual Power Consumption Values - Bigger layouts may require additional Power Supply Units. Use the following values to calculate the maximum number of panels per PSU:
